Label Printers

Adjust LT5c

In Brief

The LT5C - CYMK + White printer offers professional five-color narrow-band printing quality for a large number of markets. It is ideal for printing durable labels, water resistant labels for beverage, cosmetics and much more!

is it right for me?

This LED technology opens the door to a variety of printable media types that other printers simply cannot handle. Toner printing technology makes it possible to use untreated materials to further lower the cost of producing labels.

Subscribe to the Newsletter

LT5C Label Printer - CMYK + White

Print white on Standard or Special materials (transparent, metallic, dark, etc.)

The LT5C - CYMK + White printer offers professional five-color narrow-band printing quality for a large number of markets. It is ideal for printing durable labels, water resistant labels for beverage, cosmetics and much more!

Main Features:

  • CYMKW five-color printing
  • Durable labels (UV, water, abrasion)
  • Print on transparent, dark or metallized materials
  • Use pre-die cut or continuous reels
  • Low melting temperature ensures greater flexibility of materials
  • Print speed: up to 9m/min
  • Brilliant, high-resolution printing (1200 x 1200 dpi)


Fifth color White
The fifth color station allows the printing of white, making it easy to print on transparent or dark materials. This feature guarantees the possibility of reaching a large number of markets that it would not be possible to serve otherwise.


LED printing technology and variety of materials
Thanks to a low melting temperature, LT5C is able to print on a wide range of supports, in particular on temperature-sensitive plastics.

This LED technology opens the door to a variety of printable media types that other printers simply cannot handle. Toner printing technology makes it possible to use untreated materials to further lower the cost of producing labels.

Managing print media
LT5C supports rolls with a width from 25.4 mm to 130 mm with a maximum external diameter of 150 mm, thus allowing the use of different paper formats. Two types of sensors are used to determine the ideal printing position for black notch and label gap, thus making it possible to print both on pre-die-cut and continuous material.
The automatic cutter ensures a precise end of the job, allowing printing quickly and efficiently.

Ease of use
LT5C is intuitive and easy to install, requires minimal training and no special technical skills. Desktop-like configuration allows easy access to materials
of consumption. Reels of different materials can be changed quickly and the consumables have a high capacity to ensure prolonged printing.
The 4-inch LCD display and paper guides make loading material simple and printing labels on demand.

esempi di etichette stampate con Afinia Lt5
Examples of labels

Technical Specifications

Categoria Specifiche
Metodo di Stampa Metodo di Stampa Digitale a 5 LED a colori Elettrofotografico completo
Formato Supporto Rotolo
Tipo Supporto Carta comune, Pellicola, Etichetta in carta comune, Etichetta in carta lucida, Etichetta in pellicola, Etichetta sintetica
Larghezza Supporto 25.4 - 130.0mm
Spessore Supporto 0.076 - 0.25mm
Lunghezza Etichetta 12.7 - 1,320.8mm
Larghezza Etichetta 25.4 - 126.0mm
Rilevamento Supporto Gap, Marca Nera (stampata sul retro del liner), Continuo (nessuno)
Diametro Esterno Rotolo Massimo Ф203.2mm (Ф8")
Diametro Interno Nucleo Ф76.2mm (Ф3")
Direzione Ventilazione Rotolo Fronte-fuori, Fronte-dentro
Larghezza di Stampa Massima 125.76mm
Margine di Stampa Minimo 2.12mm (tutti i lati)
Lunghezza Supporto Tagliabile Minima 101.6mm
Risoluzione di Stampa 1200 x 1200 dpi & 600 x 600 dpi
Velocità di Stampa Massima 152.4mm/s (6ips)
Interfaccia 1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (Alta Velocità)
Protocollo TCP/IP
Linguaggio di Stampa Emulazione PCL 5c, Emulazione PCL 6 (XL), Adobe PostScript 3
Sistemi Operativi Supportati Windows 10, Windows 8, Windows Server 2016 & 2012
Processore CPU ARM da 1.2 GHz
Memoria 2048 MB
Disco Rigido 250 GB
Font Adobe PostScript 136 font, Emulazione PCL 81 font scalabili, 4 font bitmap
Sensori Supporto Sensore gap a trasmissione regolabile, Sensore di marca nera riflessiva regolabile (sul retro del liner)
Taglierina Automatica Lama rotante taglio completo
Dimensioni Totali 1.040 x 477 x 441 mm
Peso (con forniture incluse) Approssimativamente 50 kg (circa 62 kg con forniture incluse)
Ambiente Operativo Operativo: 10 - 30 °C, 20 - 70% RH, Nessuna condensazione
Fonte di Alimentazione 110-127V AC ±10% / 220-240V AC ±10%
Consumo Energetico Operativo: Max. 1.200W / Medio 740W, Standby: 27W, Risparmio Energetico: <25W
Sicurezza e Ambiente Marchio GS, Marchio CE
Nella Confezione DVD-ROM, Cavo di Alimentazione
